Powder Coat - Booth

A) General Part Information

Part Number:

Part Description:

B) Volume (Number of Pieces Produced)

Annual Volume:

Lot Run Size:

C) Part Specific Information

Part Thickness (mm):

Part Envelope Length (mm):

Part Envelope Width (mm):

Part Envelope Height (mm):

Weight (Kg):

Actual Surface Area to be Painted (Sq mm):

D) Special Part Characteristics

Select Part Shape:

E) Coating Color Selection

Select Powder Coat Color:

F) Select Primer Specifications

Select Primer if needed:

Enable Expert Level Customization

Powder Coat - Booth Costing Tool

Enter Part Information

View Estimate

Enable Customization (Opt.)

Unlock Global costs

Save

Optimize Your Powder Coating Operations with Our Booth Costing Tool.the Powder Coat - Booth is the over all solution for the cost estimation and the coat analyses.This powerful tool provides manufacturers with the insights needed to accurately assess and manage the costs associated with powder coating processes, ensuring optimal profitability and efficiency.Whether you are a small shop or a large manufacturing facility, this tool is essential for staying competitive in the powder coating industry.

A) General Part Information

Part Number:-

- Part Number which is usually mentioned on the drawing. (Alphanumeric values are accepted).

Part Description:-

-Enter Part Name for example Bumper, Cover, Upper body, etc. (Alphanumeric values are accepted).

B) Volume (Number of Pieces Produced)

Annual Volume:-

- The Number of Pieces that are Required in a Year (Limit set for the tool : 1- 10000000 Nos)

Lot Run Size:-

- The Number of Parts to be Processed in a Single Setup (Less than or equal to Annual volume)

C) Part Specific Information

Part Thickness (mm):-

- Enter the Maximum thickness of the part. (Limit set for the tool : 0.8 mm - 127 mm).

Part Envelope Length (mm):-

- Enter the Longest Side of the part which is considered the overall length of the part. (Limit set for the tool : 1524 mm - 3048mm).

Part Envelope Width (mm):-

- Enter the Maximum width of the part which is considered the overall width of the part. (Limit set for the tool : 1168 mm - 3048 mm).

Part Envelope Height (mm):-

- Part Envelope Height (mm)- Enter Height of the part, which is considered overall width of the part (Limit set for the tool : 300 mm - 2438 mm).

Weight (Kg):-

- Enter the Weight of the part, which is considered overall weight of the part. (Limit set for the tool : 90 Kg - 1000 Kg).

Actual Surface Area to be Painted (Sq mm):-

- The user have to enter the Surface Area that needs to be painted. (Limit set for the tool : 929031 sq mm to 24842273 sq mm).

D) Special Part Characteristics

Select Part Shape:-

- Select part shape of the part which is shown in the drawing from the dropdown is given. - 1] Flat / Solid, 2] Tubular 3] Mesh type

E) Coating Color Selection

Select Powder Coat Color:-

- Select the Color that part needs to be coated from the following:
Black, Blue, White, Green, Orange, etc.

F) Select Primer Specifications
